Instruments Inc.
The Armed Services most trusted provider of custom linear and switching amplifiers for sonar systems and high demand applications.
TRUSTED BY THE U.S. NAVY FOR OVER 60 YEARS
We excel in the field of solid-state power amplifiers, boasting top-tier circuitry that delivers unparalleled performance and reliability. Our primary focus lies in crafting cutting-edge systems for sonar and low-frequency radio transmitters. Remarkably, the longevity of our amplifiers is demonstrated by the fact that nearly every unit manufactured by Instruments Inc. remains fully operational to this day.
Each product we offer is meticulously tailored to meet the exact specifications of our clients, guaranteeing that our amplifiers maintain peak performance levels for decades of uninterrupted service.
BUILT TO YOUR SPECIFICATIONS
Our goal is to engineer our design to meet your specific needs.
**Due to the specialized nature of our work, some units may not be available for export to all countries. Contact us today to learn more!
LINEAR AND INTEGRATED SWITCHING
AMPLIFIERS AND SENSORS
Linear Amplifiers
-
Instruments Inc. proudly presents our renowned Linear Amplifier line, a collection of reliable Class-AB amplifiers with a proven track record. From compact benchtop units to expansive rack-mounted cabinets, these standardized amplifiers offer versatility in application. Delivering up to 6500 watts continuously and 16.5 kW pulsed, across a wide frequency band of up to 100 kHz, they maintain low Total Harmonic Distortion (THD) even under full power. With their expansive bandwidth and exceptional performance, the Linear Amplifier line is the ideal choice for comprehensive in-lab testing across a diverse range of transducers.
Spec sheets upon request.
Voltage and Current Sensors
-
Our voltage and current sensors mirror the electrical functionality of wideband potential transformers and shielded current transformers. They exhibit an impressive capacity to withstand common mode voltage of up to 1000 V at frequencies reaching 200 kHz, maintaining precise accuracies in both magnitude and phase. Ensuring precise phase information necessitates simultaneous sensing of voltage and current at a singular point. Positioned between the outputs of power amplifiers and loads, our Voltage and Current Transformers (VITs) feature single-ended outputs with a 50 ohm source resistance. These analog monitor voltages faithfully replicate the waveforms of the voltage and current under test, maintaining accurate proportions in magnitude and matched phase shifts between channels. Sustaining the validity of phase information requires careful matching of low-level output cables in length, termination, and characteristics. Monitor signals are conveniently accessible via an MS-type connector on the rear, as well as BNC connections on the front panel.
Spec sheets upon request.
Integrated Switching Amplifiers
-
Instruments Inc.’s custom line of Class-D PWM Switching Amplifiers are suited for high-power applications where efficiency and high power-density are critical, with upwards of 100 kW potential in a single cabinet, and which also may be combined in integrated amplifier systems for higher power levels. Output frequencies range from 20 Hz to 160 kHz, depending on transformer limitations. These amplifiers are suitable for both shipboard sonar systems and land-based low frequency radio transmission. While many models are available in standardized packaging, we offer complete customization of power handling, output specifications, and ultimately, chassis configuration. Single-channel and multi-channel configurations are available, and our technical expertise and experience allows us to deliver low-distortion amplifiers that are ruggedized to withstand the harshest conditions, including shock resilience in accordance with MIL-S-901D.
Spec sheets upon request.
Our 4th generation family owned business has proudly led the industry to create the most trusted and longest lasting power amplifiers for over 60 years. Our best in class circuitry production ensures reliability and performance, even when abused by operation error. Nearly all of the products we have ever built remain operational to this day.
SERVING THE MILITARY AND ITS ALLIES SINCE 1961
A WOMAN-OWNED
4th GENERATION FAMILY BUSINESS
Instruments Inc. has a proud legacy and dedicated staff with decades of specialized knowledge.
Our team is ready to assist you to build the best power amplifier to meet your needs.
"2023 Outstanding Supplier Partnership Award: In recognition for continued partnership and outstanding customer support to our family of Navy Signal Analysis System products!"
— BAE Systems, Inc.
“Kim and the Instruments Inc. team have been amazing to work with. They deliver top notch products, and their engineers are ready to roll up their sleeves and offer deep technical assistance on a moment’s notice. It’s been a pleasure working with them, and I look forward to continued business together.”
— Selectron Inc.
“You have excellent support; we appreciate the forthrightness and access to technical experts.”
— GeoSpectrum
